POWER BANKS

MagSafe Compatible Magnetic Charging

• Snap-On Wireless Alignment: Built with strong integrated alignment magnets that lock directly onto the back of your iPhone (12 through 16/17 series) or any MagSafe-compatible smartphone case for secure, slip-free charging.

• Wireless Charging Speeds: Flexibly scales across 5W / 7.5W / 10W / 15W Max depending on your phone’s receiving capability.

🔌 All-In-One Built-In Cable & Stand

• Integrated USB-C Cable: Features a built-in fast charging USB-C cord integrated right into the body, eliminating the need to pack separate cords for your phone or when recharging the power bank.

• Foldable Viewing Stand: Outfitted with an integrated zinc-alloy kickstand on the back, allowing you to prop up your phone vertically or horizontally for hands-free video calls and movie streaming while it charges.

⚡ Power Output & Fast-Charging Protocols

• 22.5W Wired Fast Charging: Pushes high-speed power outputs up to 22.5W Max via the USB-C interface.

• Supported Input/Output Specifications:

  • USB-C Input (Recharging the Power Bank): 5\text{V} \mathrel{\ deputy} 3\text{A}, 9\text{V} \mathrel{\ deputy} 2\text{A}, 12\text{V} \mathrel{\ deputy} 1.5\text{A}$ (18W Max).

  • USB-C Output: 5\text{V} \mathrel{\ deputy} 3\text{A}, 9\text{V} \mathrel{\ deputy} 2.22\text{A}, 10\text{V} \mathrel{\ deputy} 2.25\text{A}, 12\text{V} \mathrel{\ deputy} 1.67\text{A} (22.5W Max).

  • Total Combined Output: $5\text{V} \mathrel{\ deputy} 3\text{A}$ (15W Max total when utilizing wired and wireless options simultaneously).

• Broad Protocol Matching: Fully compatible with universal quick-charging standards including PD3.0, PD2.0, QC3.0, QC2.0, AFC, FCP, and SCP.

🔋 Battery Capacity & Low-Current Trickle Mode

• 10,000mAh Cell Capacity: Houses a premium $38.5\text{Wh}$ Lithium-Polymer core (Rated capacity sits at roughly 5,800mAh).

• Low-Current Output Mode: Includes specialized circuitry designed to safely charge delicate low-power hardware like Bluetooth earbuds, smartwatches, and fitness trackers without over-cycling.

• LED Status Readout: Equipped with an active display showing the exact remaining power percentage alongside a dedicated icon signaling wireless charging status.

📐 Physical Profile, Safety & Airline Compliance

• Materials: Engineered out of V0 flame-retardant Polycarbonate (PC) paired with a robust zinc alloy mechanical stand.

• Dimensions:104.5 \times 68 \times 22.8\text{ mm} (A compact pocketable block shape that won’t block your phone’s camera lenses).

• Weight: 216g.

• Airlines Safe & Fully Certified: Rated under the standard 100Wh restriction, making it completely legal and safe for flight carry-on luggage. Fully certified compliant with CCC, CE, FCC, RoHS, EAC, UKCA, and UN38.3 benchmarks.

Here are the simple key specs for the ACEFAST M7 PWRup 10,000mAh Power Bank:

🔋 Capacity & Battery

• Capacity: 10,000mAh

• Rated Capacity: 5,500mAh

• Battery Lifespan: Premium lithium battery cells engineered to retain 80% health after 300+ full charge cycles.

⚡ Power & Fast Charging

• Maximum Output: 30W Power Delivery (PD)

• Integrated Cable: Features a built-in USB-C cable, so you can charge your devices on the go without carrying an extra wire.

• Port & Output Split:

  • USB-C Port 1 / Port 2 (and Built-in Cable): Up to 30W Max input/output (Supports PD3.0, PPS, and QC4+).

  • USB-A Port: Up to 22.5W Max output (Supports Huawei SuperCharge / SCP and QC3.0).

• Triple Charging: Can power up to 3 devices simultaneously at a combined shared output of 15W.

• Protocols: Wide compatibility including the latest UFCS universal fast charging standard, alongside PD, PPS, QC, AFC, and FCP.

1.96″ TFT HD Smart Color Display

• Real-Time Dashboard: Outfitted with a vibrant color screen that provides instant insights. A single tap displays exact battery percentage, remaining charge or discharge time, real-time power output per port, and battery cell temperature.

• Smart Power Management: Features an energy-saving layout. A double-click completely powers the unit off, and the screen automatically goes into standby after 30 seconds of inactivity to preserve power.

⚡ Blazing-Fast 100W Output & Multi-Port Tech

• 100W Laptop Fast Charging: The built-in USB-C cable delivers up to a massive 100W Max output ($20\text{V} \mathrel{\ deputy} 5\text{A}$), allowing you to charge power-heavy laptops like the MacBook Pro at full speed.

• Triple-Device Simultaneous Power: Dynamically balances and distributes energy across three separate outputs:

  • Built-in USB-C Cable: Up to 100W max output.

  • Dedicated USB-C Port: Up to 45W output.

  • Dedicated USB-A Port: Up to 22.5W output ($10\text{V} \mathrel{\ deputy} 2.25\text{A}$).

• Universal Protocol Matching: Fully handles nearly all major quick-charging frameworks including AVS, PPS, PD3.0, PD2.0, QC4+, QC3.0, QC2.0, AFC, FCP, and SCP.

• Pass-Through Charging: Equipped with pass-through circuitry, letting you charge your devices safely while the power bank itself is plugged in and recharging.

🔋 Battery Core & Intelligent Thermal Regulation

• 20,000mAh High Capacity: Houses a premium $71.1\text{Wh}$ lithium-polymer cell setup (rated capacity sits at 11,000mAh at $5\text{V} \mathrel{\ deputy} 3\text{A}$).

• Extended 300-Cycle Lifespan: Engineered for high longevity, retaining over 80% of its original capacity even after 300 full charge-and-discharge cycles.

• Smart Temperature Control: An advanced internal thermal matrix constantly scans temperatures 40 times per second to prevent overheating and maintain smooth energy conversion.

🧣 Built-In Dual-Function Cable & Carry Design

• Tangle-Free Cable-Lanyard: Features a built-in, heavy-duty braided USB-C cable that securely folds back into the chassis to double as a carrying lanyard. You can charge your phone and hold the loop around your wrist in one motion.

• Premium Aesthetic: Built with a scratch- and stain-resistant metallic paint finish wrapped over a fire-safe, V0-grade flame-retardant Polycarbonate (PC) structural shell.

📐 Physical Profile, Safety & Travel Approvals

• Dimensions: $103.7 \times 51.8 \times 51.8\text{ mm}$ (compact block design that packs a high capacity into a reduced footprint).

• Weight: 408g.

• Airline Certified Safe: Rated at 71.1Wh, comfortably falling below the standard 100Wh international flight restriction for worry-free carry-on travel. Fully meets CCC, FCC, CE, EAC, RoHS, and UN38.3 global safety benchmarks.

• Cell Capacity: 20,000mAh (72Wh).
• Maximum Total Power Output: 87W combined across multiple ports.
• Single-Port Maximum Output: 65W via either the built-in USB-C cable or the dedicated USB-C port.
• Port Selection:
  • 1 x Integrated USB-C cable.
  • 1 x USB-C input/output port.
  • 1 x USB-A output port (max 22.5W).

• Recharge Time: Fully recharges in under 1.5 hours when utilizing a 65W Power Delivery (PD) wall adapter.

• Laptop Compatibility: The 65W maximum output is powerful enough to handle high-demand electronic devices like a ASUS ROG Ally in full 30W Turbo mode.
• Trickle-Charging Mode: Double-pressing the power button turns on a low-current mode. This prevents the power bank from shutting off while charging smaller gadgets like wireless earbuds or smartwatches.
• Flight Safety: The device stays well below the 100Wh legal threshold, making it airline-travel approved and safe for carry-on luggage.

• Fusion Hybrid Design: Functions as a standalone portable battery or plugs directly into a wall outlet via foldable AC prongs to serve as a standard wall block.
• 65W High-Speed Output: Delivers up to 65W of power via a single port in both wall charger and battery modes, which is enough to fast-charge a MacBook Pro or Air.
• Dual USB-C Ports: Allows for charging two devices at the same time. When both ports are active, it intelligently distributes power (typically 45W via USB-C1 and 20W via USB-C2).
• Smart LCD Display: Features an integrated 1.3-inch screen providing live tracking of remaining battery percentage, input/output wattage, charging time, and battery health.
• Two-Way Recharging: The internal battery can be refueled either by plugging the device into a wall outlet or through a USB-C port at up to 30W.
